Viceroy TDS 1/1 GB Drawing No 35

[Alan]

The last one, this has been a interesting project, i hope it is useful to as many people as possible. these may be of interest to everyone with a love of all thing mechanical. I am sorry but please do not ask for a photocopy of these, I do not have the time or facility to do so. I have not tested do download them, but you can right click and save the image, then rotate them. I have not tried printing them from the save imge, the images as I stated on an earlier drawing are from A3 originals, the only way for me to scan them in was by using a camera and cropping the images to fit the criteria of the webpage 1600 pixels wide by 3000 high. This is No 35.

Aviary Photo_130816825977157214.png (4.29 MiB) Viewed 7530 times

[dazz]

Hello
I am sure that future generations of Denford TDS owners will appreciate your efforts.
A very useful reference. Much more information that is usually available for any lathe.

I didn't know that Denford made a chip screen. One of the few Denford accessories I don't have.

[Alan]

Thanks Dazz, my hope was that they would be useful to others, not making profit off anyone, cheers for the comments, Alan.

[rpwilson]

Mine came with one of those tip up chip guards hinged over the chuck, which I never use because its too small for the faceplate or the big 4 jaw, and useless if the cutting operation isn't directly in front of the chuck. I might make one as shown on the first download, at least the shield moves with the tool

[dazz]

Hi
Some time ago I purchased a piece of polycarbonate sheet (shatter proof) to make a chip guard. I just haven't got around to making it yet. Too many other projects.
