when using the vertical router, the spindle is not switching on. I have tried to switch it on via the control panel but the dial icon is not showing. All other function of the machine are good, ie homing, moving x,y & z via a .fnc file. I have tried another machine 2600Pro and the software can be used to switch on the spindle manually. Is this a problem with the sensors or the motor? The switch on the head is ON.
Thanks
Spindle not rotating- Vertical Router
Moderators: Martin, Steve, Mr Magoo
-
Denford Admin
- Site Admin
- Posts: 3649
- Joined: Fri 10 Feb , 2006 12:40 pm
- Hardware/Software: Go to User Control Panel > Profile
Enter as much information about your CNC hardware and software as you can - it makes it easier for everyone to know what you're talking about then. - Location: Sunny Brighouse
- Contact:
-
bradders
- CNC Guru
- Posts: 1251
- Joined: Mon 13 Feb , 2006 12:35 pm
- Location: Brighouse, England
- Contact:
Hi,
No one has switched the Spindle motor off with the swicth on the motor itself have they ?
The carbon brushes in this motor are consumables, are they worn out ?
Part No BI00307MB
No one has switched the Spindle motor off with the swicth on the motor itself have they ?
The carbon brushes in this motor are consumables, are they worn out ?
Part No BI00307MB
Last edited by bradders on Tue 10 Mar , 2009 10:57 am, edited 1 time in total.
